ALAN Xtreme Gravel Carbon Frameset: A Fusion of Performance and Versatility
The ALAN Xtreme Gravel Carbon Frameset is a cutting-edge gravel bike frame, blending features from previous models with modern design elements like fully integrated cable routing. This monocoque carbon frame excels in vibration absorption, while the uniquely shaped fork ensures exceptional bike handling on various terrains. Suitable for both gravel racing and adventure, it offers a mix of reactivity, comfort, and practicality with bikepacking support.
Call or send us an email if you would like to customize any of the specs
ALAN frames are made with great effort by hand. We have some frame sets in stock, but delivery times can be up to 6 weeks.
Detailed Specifications:
SHIFT LEVERS: SRAM Rival AXS 1x12sp Hydraulic
REAR DERAILLEUR: SRAM Rival AXS XPLR 12sp
CRANKSET: SRAM Rival AXS T40
CASSETTE: SRAM Rival 12 10-44t
CHAIN: SRAM Rival 12 Speed
BOTTOM BRACKET: BB86 (86,5x41)
BRAKES: SRAM Rival AXS Hydraulic Disc, Flat mount
WHEELS: Fulcrum Racing 6 DB
TIRES: Vittoria Terreno Dry 38mm
SEAT POST MODEL: DEDA Zero1
SADDLE: Selle Italia Model X
BAR TAPE: DEDA Black
HANDLE BAR: DEDA Zero1
STEM: DEDA Zero1
FORK: Carbon Monocoque, 490g
GROUPSET: SRAM Rival AXS XPLR 1x12
GEAR RATIO: 10-44
NUMBER OF CHAINRINGS: 1
SHIFTING ACTUATION: Electronic
BRAKE TYPE: Disc Brake
WHEEL SIZE: 28" (622mm)
COLOR: Blue/Purple
CABLE ROUTING: Internal
Key Features:
- Carbon frame weight: 1180g. Carbon fork: 490g
- Tapered headtube (1”1/2 top - 1”1/2 bottom)
- Lightweight monocoque carbon fork (490g) with 3-pack mounts on each fork blade.
- BB86 bottom bracket (86.5x41) for a sturdy and responsive build.
- Flat mount disc brakes and compatibility with max tire sizes of 700x45 or 650bx50.
- Seat tube ID of 27.2 mm, accommodating a wide range of seatpost options.
- Multiple mounting points for racks, mudguards, and bottles, including a food bag mount on the top tube.
- Available in unique colors: XG3 Green Purple, XG4 Golden Purple, XG5 Blue Purple.
