ALAN Xtreme Gravel Carbon Bike | XG3 Green/Purple | Rival AXS XPLR 2x12 Speed

ALAN Xtreme Gravel Carbon Frameset: A Fusion of Performance and Versatility

The ALAN Xtreme Gravel Carbon Frameset is a cutting-edge gravel bike frame, blending features from previous models with modern design elements like fully integrated cable routing. This monocoque carbon frame excels in vibration absorption, while the uniquely shaped fork ensures exceptional bike handling on various terrains. Suitable for both gravel racing and adventure, it offers a mix of reactivity, comfort, and practicality with bikepacking support.

*Call or send us an email if you would like to customize any of the specs*

Detailed Specifications:

SHIFT LEVERS: SRAM Rival AXS 2x12sp Hydraulic

FRONT DERAILLEUR: SRAM Rival AXS 12sp

REAR DERAILLEUR: SRAM Rival AXS XPLR 12sp

CRANKSET: SRAM Rival AXS 33/46T

CASSETTE: SRAM Rival 10-36 12speed

CHAIN: SRAM Rival 12 Speed

BOTTOM BRACKET: BB86 bottom bracket (86.5x41)

BRAKES: SRAM Rival AXS Hydraulic Disc, Flat mount

WHEELS: Fulcrum Racing 6 DB

TIRES: Vittoria Terreno Dry 38mm

SEAT POST MODEL: DEDA Zero1

SADDLE: Selle Italia Model X

BAR TAPE: DEDA Black

HANDLE BAR: DEDA Superzero Gravel Alloy

STEM: DEDA Zero1

FORK: Carbon Monocoque, 490g

GROUPSET: SRAM Rival AXS XPLR 2x12

NUMBER OF CHAINRINGS: 2

SHIFTING ACTUATION: Electronic

BRAKE TYPE: Disc Brake

WHEEL SIZE: 28" (622mm)

COLOR: Golden Purple

CABLE ROUTING: Internal

Key Features:

• Carbon frame weight: 1180g. Carbon fork: 490g
• Tapered headtube (1”1/2 top - 1”1/2 bottom)
• Lightweight monocoque carbon fork (490g) with 3-pack mounts on each fork blade.
• BB86 bottom bracket (86.5x41) for a sturdy and responsive build.
• Flat mount disc brakes and compatibility with max tire sizes of 700x45 or 650bx50.
• Seat tube ID of 27.2 mm, accommodating a wide range of seatpost options.
• Multiple mounting points for racks, mudguards, and bottles, including a food bag mount on the top tube.
• Available in unique colors: XG3 Green Purple, XG4 Golden Purple, XG5 Blue Purple.
