ALAN XC Gravel Carbon Modell | RC7 EMERALD WHITE | Rival XPLR AXS 1x12 Speed

ALAN XC Gravel Carbon Frameset: A High-Speed Gravel Racing Marvel

The ALAN XC Gravel Carbon Frameset is meticulously designed for gravel racing enthusiasts. It's engineered to deliver top performance on various terrains including asphalt, gravel, and dirt roads, without the extra weight of bikepacking gear. This frameset stands out with its fully integrated cable routing, offering both a smooth look and aerodynamic efficiency. The high modulus carbon fiber monocoque frame, weighing just 1,150 g, is available in sizes S to XXL.

Call or send us an email if you would like to customize any of the specs

ALAN frames are made with great effort by hand. We have some frame sets in stock, but delivery times can be up to 6 weeks.

Detailed Specifications:

SHIFT LEVERS: SRAM Rival AXS 1x12sp Hydraulic

REAR DERAILLEUR: SRAM Rival AXS XPLR 12sp

CRANKSET: SRAM Rival AXS T40

CASSETTE: SRAM Rival 12 10-44t

CHAIN: SRAM Rival 12 Speed

BOTTOM BRACKET: BB86 (86,5x41)

BRAKES: SRAM Rival AXS Hydraulic Disc, Flat mount

WHEELS: Fulcrum Racing 6 DB

TIRES: Vittoria Terreno Dry 38mm

SEAT POST MODEL: DEDA Zero1

SADDLE: Selle Italia Model X

BAR TAPE: DEDA Black

HANDLE BAR: DEDA Zero1

STEM: DEDA Superbox

FORK: Carbon Monocoque, 490g

GROUPSET: SRAM Rival AXS XPLR 1x12

GEAR RATIO: 10-44

NUMBER OF CHAINRINGS: 1

SHIFTING ACTUATION: Electronic

BRAKE TYPE: Disc Brake

WHEEL SIZE: 28" (622mm)

COLOR: Green Purple/Turquoise

CABLE ROUTING: Internal

Key Features:

• High modulus carbon fiber monocoque frame, providing exceptional stiffness and vibration absorption.
• Integrated Deda DCR headset included, enhancing the bike's clean lines and functionality.
• Monocoque carbon fork weighing 490g, with a tapered headtube (1”1/2 top - 1”1/2 bottom) for precise steering.
• Superior handling and quick acceleration, ideal for fast terrains and rapid directional changes.
• Powerful and modulated braking performance with flat mount disc brakes, suitable for all conditions.
• Rear thru-axle (12x142mm) and front thru-axle (12x100mm) for enhanced stability and precision.
• Bottom bracket BB86 (86.5x41) and seat tube ID of 27.2 mm, catering to a variety of component choices.
• Maximum tire size compatibility of 700x42, suitable for diverse gravel paths.
