ALAN Super Gravel AL Gravel Bike | SGA1 BLUE | GRX400 2x10 Speed

ALAN Super Gravel AL: A Versatile and Responsive Aluminum Gravel Bike

The ALAN Super gravel AL features a new aluminium Ergal tubeset and a semi integrated cable routing for a clean look with no cable clutter in the steering area. The easy and responsive handling allow to have a versatile and comfortable bike for gravel.

Designed for versatility and comfort on gravel, it exhibits easy and responsive handling. The frame's rear and front thru-axles (12x142mm and 12x100mm respectively) contribute to its stability and precision. With a weight of just 1.600 g and available in sizes XS to XXL, this bike is tailored for a range of cyclists.

Call or send us an email if you would like to customize any of the specs

ALAN frames are made with great effort by hand. We have some frame sets in stock, but delivery times can be up to 6 weeks.

Detailed Specifications:

SHIFT LEVERS: Shimano GRX400 2x10 hydraulic

FRONT DERAILLEUR: Shimano GRX400

REAR DERAILLEUR: Shimano GRX400

CRANKSET: Shimano GRX400 30/46

CASSETTE: Shimano 11-32

CHAIN: KMC 10-Speed

BOTTOM BRACKET: BSA

BRAKES: Shimano GRX400 hydraulic

WHEELS: Shimano RS171 DB

TIRES: Vittoria Terreno Dry 38mm

SEAT POST MODEL: DEDA Zero1

SADDLE: Selle Italia Model X

BAR TAPE: Prologo

HANDLE BAR: DEDA Zero1

STEM: DEDA Superbox

FORK: Carbon Monocoque, 450g

GROUPSET: Shimano GRX400 2x10 Speed

NUMBER OF CHAINRINGS: 2

SHIFTING ACTUATION: Mechanical

BRAKE TYPE: Disc Brake

WHEEL SIZE: 28" (622mm)

COLOR: blue-silver

CABLE ROUTING: Internal

Key Features:

• Frame weight: 1,600g
• Alloy frame with semi-integrated cable routing, offering a clean and streamlined look.
• Support for frame and fork-mounted racks and mudguards, enhancing its all-terrain utility.
• Tapered headtube (1”1/2 top - 1”1/2 bottom)
• BSA threaded bottom bracket shell, suitable only for cranksets with Q-Factor equal or wider than 150 mm.
• Flat mount disc brake system for reliable and efficient braking performance.
• Seat tube ID of 27.2 mm, accommodating a wide range of seatpost options.
• Compatible with tire sizes up to 700x42 or 650bx47, offering flexibility for different terrains.
