ALAN Crossover: A Versatile and Responsive Aluminum Gravel Bike

The ALAN Crossover is a new addition to the world of gravel biking, featuring a modern Ergal alloy frame with semi-integrated cable routing for a neat and uncluttered steering area. Designed for versatility and comfort on gravel, it exhibits easy and responsive handling. The frame's rear and front thru-axles (12x142mm and 12x100mm respectively) contribute to its stability and precision. With a weight of just 1.600 g and available in sizes XS to XL, this bike is tailored for a range of cyclists.

*Call or send us an email if you would like to customize any of the specs*

Detailed Specifications:

SHIFT LEVERS: Shimano GRX400 2x10 hydraulic

FRONT DERAILLEUR: Shimano GRX400

REAR DERAILLEUR: Shimano GRX400

CRANKSET: Shimano GRX400 30/46

CASSETTE: Shimano 11-32

CHAIN: KMC 10-Speed

BOTTOM BRACKET: BSA

BRAKES: Shimano GRX400 hydraulic

WHEELS: Shimano RS171 DB

TIRES: Vittoria Terreno Dry 38mm

SEAT POST MODEL: DEDA Zero1

SADDLE: Selle Italia Model X

BAR TAPE: Prologo

HANDLE BAR: DEDA Zero1

STEM: DEDA Zero1

FORK: Carbon Monocoque, 450g

GROUPSET: Shimano GRX400 2x10 Speed

NUMBER OF CHAINRINGS: 2

SHIFTING ACTUATION: Mechanical

BRAKE TYPE: Disc Brake

WHEEL SIZE: 28" (622mm)

COLOR: Green Purple

CABLE ROUTING: Internal

Key Features:

• Frame weight: 1,600g
• Alloy frame with semi-integrated cable routing, offering a clean and streamlined look.
• Support for frame and fork-mounted racks and mudguards, enhancing its all-terrain utility.
• Tapered headtube (1”1/2 top - 1”1/2 bottom)
• BSA threaded bottom bracket shell, suitable only for cranksets with Q-Factor equal or wider than 150 mm.
• Flat mount disc brake system for reliable and efficient braking performance.
• Seat tube ID of 27.2 mm, accommodating a wide range of seatpost options.
• Compatible with tire sizes up to 700x42 or 650bx47, offering flexibility for different terrains.
• Available in vibrant colors: CVN3 Green Purple and CVN4 Golden Purple.
