ALAN Super Gravel AL Gravel Bike | CVN3 GREEN PURPLE | Rival AXS XPLR 1x12 Speed

ALAN Super Gravel AL: A Versatile and Responsive Aluminum Gravel Bike

The ALAN Super gravel AL features a new aluminium Ergal tubeset and a semi integrated cable routing for a clean look with no cable clutter in the steering area. The easy and responsive handling allow to have a versatile and comfortable bike for gravel.

Designed for versatility and comfort on gravel, it exhibits easy and responsive handling. The frame's rear and front thru-axles (12x142mm and 12x100mm respectively) contribute to its stability and precision. With a weight of just 1.600 g and available in sizes XS to XXL, this bike is tailored for a range of cyclists.

Call or send us an email if you would like to customize any of the specs

ALAN frames are made with great effort by hand. We have some frame sets in stock, but delivery times can be up to 6 weeks.

Detailed Specifications:

SHIFT LEVERS: SRAM Rival AXS 1x12sp Hydraulic

REAR DERAILLEUR: SRAM Rival AXS XPLR 12sp

CRANKSET: SRAM Rival AXS T40

CASSETTE: SRAM Rival 12 10-44t

CHAIN: SRAM Rival 12 Speed

BOTTOM BRACKET: BSA

BRAKES: SRAM Rival AXS Hydraulic Disc, Flat mount

WHEELS: Fulcrum Racing 6 DB

TIRES: Vittoria Terreno Dry 38mm

SEAT POST MODEL: DEDA Zero1

SADDLE: Selle Italia Model X

BAR TAPE: DEDA Black

HANDLE BAR: DEDA Zero1

STEM: DEDA Zero1

FORK: Carbon Monocoque, 450g

GROUPSET: SRAM Rival AXS XPLR 1x12

GEAR RATIO: 10-44

NUMBER OF CHAINRINGS: 1

SHIFTING ACTUATION: Electronic

BRAKE TYPE: Disc Brake

WHEEL SIZE: 28" (622mm)

COLOR: Green Purple

CABLE ROUTING: Internal

Key Features:

• Frame weight: 1,600g
• Alloy frame with semi-integrated cable routing, offering a clean and streamlined look.
• Support for frame and fork-mounted racks and mudguards, enhancing its all-terrain utility.
• Tapered headtube (1”1/2 top - 1”1/2 bottom)
• BSA threaded bottom bracket shell, suitable only for cranksets with Q-Factor equal or wider than 150 mm.
• Flat mount disc brake system for reliable and efficient braking performance.
• Seat tube ID of 27.2 mm, accommodating a wide range of seatpost options.
• Compatible with tire sizes up to 700x42 or 650bx47, offering flexibility for different terrains.
